HP10124 (Basic) Paddle Valve In Cab Control Kit w/ Mechanical Gauge, Independent Fill

Overview

Pacbrake's Paddle Valve In-Cab Controls are an economical option for operating your Air Springs (or other pneumatic accessories) from the driver's seat!

Basic kits provide customers with a less expensive option for operating their Air Suspension Kits with dash switch(es) that attach directly to the Air Springs and an existing compressor or onboard air system.

Use this kit in conjunction with one of our Air Compressor Kits and/or Air Tank Kits to make your own complete and customized onboard air system!

Take your towing, hauling, 4x4'ing and all other onboard air management to the next level with Pacbrake In-Cab Controls.

Product Description

Pacbrake's Basic Paddle Valve In-Cab Control Kits with Mechanical Gauge display, is designed to integrate In-Cab Controls with a pre-existing Onboard Air system, for 'Independent' Air Spring or pneumatic accessory activation with the push of a button.

Independent Activation (or Inflation) is simply two separate switches that allow for inflation/deflation of each Air Spring individually.

A comparable Basic Simultaneous Activation Kit (HP10133) is also available for those that want to utilize two separate switches, allowing for inflation/deflation of each Air Spring individually.

Mechanical back-lit Gauges display pressure from 0psi to 150psi at 10psi increments — numeric markings at 0, 50, 100, & 150psi — allowing for the monitoring and adjusting of your Air Spring pressure.

This Kit Includes:

Dual Paddle Valve Dash Switch w/ Mechanical Dual Needle Gauge — Independent Activation
Includes Installation Hardware & Hardware to connect to an existing Onboard Air system only
Does not include any pre-built harnesses or compressor (See Premium Kit: HP10098, which includes a 12VDC HP325 Series Air Compressor and does not require an Air Tank)

This kit does not include an Air Compressor (sold separately):

HP10142 — 12VDC HP325 Series Compressor — (Chrome)
HP10142-B — 12VDC HP325 Series Compressor — (Matte Black)

PLEASE NOTE: This kit requires the use of an Air Compressor (or existing onboard air system) to work with an Air Suspension kit

WARNING: HP325 Series Air Compressors (sold separately) cannot be used with an Air Tank larger than 2 ½ Gallons

This kit does not include an Air Tank (sold separately):

HP10053 — 1/2 Gallon Air Tank — (Black Steel)
HP10266 — 1/2 Gallon Air Tank — (Polished Aluminum)
HP10050 — 2 ½ Gallon Air Tank — (Black Steel)
HP10267 — 2 ½ Gallon Air Tank — (Polished Aluminum)

PLEASE NOTE: If adding an air tank, a pressure switch is required; HP10110 for 105-135 PSI / HP10111 for 85-105 PSI

Vehicle Application

Universal

Application Notes

This kit does not include and requires the use of an air compresor (or existing onboard air system) to work with an Air Suspension system
If adding an air tank, a pressure switch is required;
(HP10110) for 105-135 PSI / (HP10111) for 85-105 PSI
Mechanical Gauges require a minimum of 6" (101.6mm) of clearence behind the bracket for routing of the air line

Features

Operate your Air Springs (or other pneumatic accessories) right from the driver's seat - an existing Air Compressor is required
Independent Activation/Inflation; inflates/deflates both air springs at the same time
Use this kit in conjunction with one of our air tank kits and air compressor kits to build your own customizable onboard air system
