HP10719 2.5 Gallon Air Tank Kit

Overview

Pacbrake HP10719 2.5-gallon Air Tank Kit integrates with the BRAVO HP30040-QM and HP30040-QM-R (with remote) systems to store compressed air for faster response and accessory use. Tanks enable quicker air spring adjustments and improved onboard air functionality.

Product Description

The HP10719 2.5‑gallon Air Tank Kit delivers increased air storage for BRAVO 2.0 systems. This higher-capacity configuration is suited for users requiring greater air reserve for faster adjustments and accessory operation.

KIT DETAILS:

2 1/2 Gallon Steel Air Tank with black powder-coated finish
Quick-Mount bracket for universal mounting
Includes all installation hardware

SPECIFICATIONS

Tank capacity: 2 1/2 (2.5) gallon
Material: Carbon Steel
Max Working Pressure: 150 PSI [1.03 MPa]
Dimensions: 21 inch x 6.9 inch x 8.4 inch (LxWxH) [534mm x 175mm x 213mm]
Weights: 11.2 lbs [5.12 kg]
Burst Pressure: 4.14 MPa [600 PSI]
Operating Temperature: -40°C TO +120°C [-40°F TO +248°F]
Tubing Connection Points: 1/4” Tubing Push-to-Connect Fittings

Vehicle Application

Universal

Application Notes

Designed for use with BRAVO systems. If using with a non-Bravo system, ensure the existing system is compatible with an added tank.
Supports modular system expansion (tank + accessories).
Kit includes everything needed to connect to an existing air management system.
